Job photos from our service calls

Every picture here was taken on one of our own commercial or industrial service calls, usually with the panel door still open, and none of them are stock. Compressors, control cabinets, a fan deck and a chiller: the equipment we open up on service calls.

Large semi-hermetic reciprocating compressor with its terminal box and suction line inside a rooftop unit
A semi-hermetic reciprocating compressor on a rooftop unit.
George Blevens in front of an open control cabinet with contactors, terminal strips and a digital controller
George Blevens at an open control cabinet: contactors, terminal strips and the unit controller.
Air-cooled chiller with condenser fans on top and chilled-water piping and a pump at its base
An air-cooled chiller, with the chilled-water piping and pump beside it.
Two black scroll compressors mounted side by side on a common base in a commercial unit
Tandem scroll compressors on a shared base inside a commercial unit.
Clamp meter hanging on the door of an open control panel lined with contactors and wiring
A clamp meter hung on the door of an open control panel full of contactors.
View looking up into a condenser section with fan motors and blades between two coil banks
Looking up into a condenser fan deck between two coil banks.
George Blevens next to a Trane reciprocating compressor in a mechanical room
George Blevens beside a Trane reciprocating compressor in a mechanical room.
Rooftop unit control compartment with control boards, a run capacitor, contactors and a clamp meter on one lead
Control boards, a run capacitor and contactors in a rooftop unit, with a meter on the lead.
Semi-hermetic compressor with its suction line and pressure controls under a condensing unit
A semi-hermetic compressor and its suction line tucked under a condensing section.
Open package unit showing contactors, a control board and a scroll compressor in one compartment
A package unit opened up: controls on the left, scroll compressor on the right.
Two scroll compressors below the open control section of a rooftop unit
Two scroll compressors below the control section of a rooftop unit.

Behind the photos

Equipment that looks like this?

Snap the nameplate and the open panel and send them over. It tells us a lot before we ever get on the roof.
